AC Brake Geared Motor

AC Brake Geared Motor Specification

Voltage
230V / 415V

Features
Compact Design, Durable, Efficient Brake System, Low Maintenance

Rated Voltage
220-415V

Motor Type
AC Induction Motor

Power Rating
0.12 kW to 5.5 kW

Starting Type
Direct-On-Line

Pressure
Standard Atmospheric

Poles Number
2/4/6

Torque
High Starting Torque

Bearing Type
Ball Bearing

Cooling Method
Fan Cooled

Standard
IS/IEC

Horse Power
0.16 HP to 7.5 HP

Rated Frequency
50/60 Hz

Sealed Type
IP55

Ambient Temperature
-10C to 50C

Current Type
AC

Efficacy
IE2 / IE3

Noise Level
Low

Product Type
AC Brake Geared Motor

Output Power
0.12 kW to 5.5 kW

Frequency (MHz)
50/60 Hz

Protect Feature
Totally Enclosed Fan Cooled (TEFC)

Phase
Three Phase

Speed
6 rpm to 2880 rpm

Power
0.16 HP to 7.5 HP

Color
Blue

Dimension (L*W*H)
Customized

Weight
Depends on Model

Shaft Diameter
Customized

Mounting Type
Foot / Flange Mounted

IP Rating
IP55

Duty Cycle
S1 Continuous

Gear Type
Helical / Worm

Lubrication
Grease Packed / Oil Lubricated

Housing Material
Cast Iron / Aluminum

Output Shaft Material
Alloy Steel, Hardened

Overload Protection
Built-in Thermal Protection

Application
Material Handling, Conveyors, Cranes, Lifts, etc.

Gear Ratio
5:1 to 100:1

Enclosure
Totally Enclosed

Insulation Class
Class F

Service Factor
1.0 - 1.15

Operational Position
Horizontal / Vertical

Brake Type
Electromagnetic AC Brake

About AC Brake Geared Motor

We are offering an extensive series of helical gearbox with motor. These products are extremely employed in the market for diverse purposes.
Manufacturing Range:
- Geared Motors Reducers - Power: 0.33 HP to 125 HP
- Output Speed: 0.4 to 585 RPM
-

Reliable Performance in Industrial Applications

Ideal for demanding environments, this AC Brake Geared Motor excels in material handling, conveyors, cranes, and lifts. Its compact, durable design ensures stable performance, even under continuous load, thanks to features like Class F insulation, high starting torque, and a service factor of 1.0-1.15. The totally enclosed fan-cooled system maintains optimal temperature, guaranteeing operational longevity.

Versatile Design and Customization Options

With both horizontal and vertical operational positions, this geared motor fits a variety of installations. The housing material can be selected from cast iron or aluminum, and shaft diameters are customizable to suit project requirements. The wide speed range (6-2880 rpm) and gear ratios allow precise adaptation to different machinery, while flange/foot mounting ensures quick integration.

Enhanced Safety and Maintenance Efficiency

Engineered for safety, this motor includes built-in thermal overload protection and IP55 sealing for dust and moisture resistance. Its low-noise, low-maintenance structure means fewer operational disruptions and reduced downtime. Lubrication options-grease-packed or oil-lubricated-contribute to smoother running and extended service life, minimizing long-term costs.

FAQ's of AC Brake Geared Motor:

Q: How does the electromagnetic AC brake function in this geared motor?

A: The electromagnetic AC brake provides rapid and precise stopping by engaging the brake instantly upon power interruption, ensuring safe operation for material handling and lifting applications.

Q: What is the recommended process for installing the motor in horizontal or vertical positions?

A: For both horizontal and vertical installation, ensure the mounting surface is level and vibration-free, use appropriate flange or foot fixtures, and adhere to wiring and lubrication guidelines as outlined in the user manual for optimal performance and safety.

Q: When should I opt for a helical versus a worm gear configuration?

A: Select a helical gear for higher efficiency and smoother operation at moderate to high speeds, while a worm gear is ideal for applications requiring high torque at lower speeds, such as lifts and conveyors.

Q: Where can this AC Brake Geared Motor be effectively used?

A: This motor is suited for material handling systems, conveyors, overhead cranes, industrial lifts, and any application needing reliable, continuous-duty operation with high starting torque and precise braking.

Q: What are the advantages of the totally enclosed, fan-cooled (TEFC) design?

A: The TEFC design protects internal components from dust, moisture, and contaminants while maintaining effective cooling, leading to improved motor longevity and lower risk of operational failure.

Q: How does built-in thermal overload protection benefit the user?

A: Integrated thermal protection safeguards the motor against overheating, automatically interrupting operation in case of excess temperature, thereby preventing costly damage and enhancing system safety.

Q: What maintenance is required to ensure low noise and durability?

A: Regularly check and replenish lubrication (either grease or oil, depending on the model), monitor for unusual vibrations or heat, and ensure the enclosure seals and fan are free from obstructions to maintain quiet, reliable performance.
