Brake Coil with Plunger

Brake Coil with Plunger Specification

Thickness
Based on design, typically ranges from 15mm to 30mm

Vehicle Type
Industrial Machinery, Cranes, Hoists (not limited to vehicles)

Shape
Open Type, Bobbin, Standard and Moulded Bakelite (Rectangular/Square/Custom Shapes)

Pressure
Not applicable (actuated electromagnetically)

Material
Bakelite / Molded Resin / Copper Winding / Steel Plunger

Loading Capacity
Depends on brake size and application (customizable)

Diameter
Standard and custom sizes available as per brake requirement

Power
Typically ranges between 20W - 40W for standard brake coils

Voltage
24V, 110V, 220V AC/DC (custom voltages available)

Application
Electro Magnetic Brake systems, industrial cranes, hoists, lifts, material handling equipment

Frequency
50Hz / 60Hz

Quality Attributes
Premium quality, reliable performance, long service life

Durability
Designed for heavy-duty industrial operation

Operating Temperature
-20C to +60C

Termination Type
Brass Screws / Terminal Blocks provided

Insulation Class
Class F / Class H (as required)

Mounting Type
Fixing arrangement as per brake design (side and base mounting holes)

Customization
Available based on size, voltage, and application

Resistance
As per design specification (typically within coil range tolerance)

Brake Coil with Plunger About

rake coils for Bhartia Culter HammerBCH AC operated Solenoid Brake used in for Cranes, Hoists, Machinery, Mining machineries, Marine, Machine tools, Earthmoving and wet and dry applications.

Shruti Engineering are the very highly acclaimed organization in this sector, engaged in manufacturing and supplying an exclusive range of AC Solenoid Magnetic Brake. These products are gaining appreciation from every where in the world for its unmatched quality and low maintenance. Our offered product range is manufactured using fine grade raw materials and modern technology and it is designed as per the specifications of our distinguished customers.

Superior Insulation and Design

This brake coil employs insulation classes F or H as needed, ensuring optimal thermal and electrical safety for industrial uses. Its mounting options (side or base) and customizable dimensions make it highly adaptable to varied brake designs and operational requirements.

Built for Performance and Reliability

Constructed with copper windings, steel plungers, and premium molded insulation, each unit is designed for enduring performance in demanding environments. Operating reliably between -20C to +60C, these coils offer dependable actuation for industrial machinery and electrical brakes.

Flexible Customization and Versatility

Users can specify coil size, resistance, voltage, and power ratings based on their application. Options in diameter, thickness (15-30mm), and shape (open, bobbin, standard or custom molded) ensure a perfect fit in a wide range of industrial systems, promoting seamless integration and efficiency.

FAQ's of Brake Coil with Plunger:

Q: How is the brake coil with plunger installed in industrial applications?

A: The brake coil is mounted using side or base mounting holes designed to fit the specific brake unit. Installation follows the brake manufacturer's arrangement, making it straightforward to fix or retrofit within cranes, hoists, or material handling systems.

Q: What are the typical voltage and power ratings available for these brake coils?

A: Standard voltage options include 24V, 110V, and 220V in both AC and DC configurations, with custom voltages available on request. Power ratings typically range from 20W to 40W, depending on brake size and specific application requirements.

Q: When should a brake coil be customized, and what options are available?

A: Customization is recommended when standard dimensions, resistance, or voltage do not match your machinery's needs. We can tailor the coil's size, power, voltage, resistance, and shape to meet unique application demands for optimal performance.

Q: Where are brake coils with plungers used most effectively?

A: These coils are primarily utilized in electromagnetic brake systems of industrial cranes, hoists, lifts, and various material handling equipment, where dependable and repeatable braking action is crucial for operational safety.

Q: What process ensures the brake coil's reliability and long service life?

A: Each coil is manufactured using premium materials like bakelite, copper, and molded resin, and undergoes rigorous quality control. The insulation class, precision winding, and sturdy termination methods all contribute to prolonged durability and superior performance under heavy-duty operations.

Q: How does using a brake coil with the right insulation class benefit industrial equipment?

A: Selecting the appropriate insulation class (F or H) allows the coil to withstand the expected thermal loads, reducing the risk of overheating and ensuring continuous safe operation in high-temperature environments.
