Electromagnetic AC Brake Gear Motor

Electromagnetic AC Brake Gear Motor Specification

Current Type
AC

Features
Electromagnetic AC Brake, Compact Design, Low Vibration, Energy Efficient

Cooling Method
IC411 (Surface Cooling)

Torque
High Starting Torque

Voltage
415 V

Rated Frequency
50 Hz

Standard
IS 325 / IEC 60034

Pressure
Standard Atmospheric

Bearing Type
Deep Groove Ball Bearing

Power Rating
0.18 kW - 7.5 kW

Rated Voltage
415 V

Noise Level
< 65 dB

Horse Power
0.25 HP to 10 HP

Ambient Temperature
-10C to +50C

Sealed Type
Totally Enclosed Fan Cooled (TEFC)

Poles Number
4 Pole

Starting Type
Direct On Line (DOL)

Motor Type
Squirrel Cage Induction Motor with Electromagnetic Brake

Efficacy
IE2/IE3 High-Efficiency

Product Type
Electromagnetic AC Brake Gear Motor

Output Power
0.18 kW to 7.5 kW

Frequency (MHz)
50 Hz

Protect Feature
Overload Protection

Phase
Three Phase

Speed
1440 RPM

Power
0.25 HP to 10 HP

Color
Blue

Dimension (L*W*H)
435 x 210 x 215 mm (approx.)

Weight
26 kg (approx.)

Shaft Diameter
28 mm (standard)

Mounting Type
Foot / Flange Mounted

IP Rating
IP55

Lubrication
Synthetic Oil Filled

Service Factor
1.0 - 1.25

Application
Cranes, Conveyor, Hoists, Elevators, Automation

Gearbox Type
Helical Worm / Inline Gearbox

Brake Type
AC Electromagnetic Shoe Brake

Duty Type
S1 Continuous Duty

Mounting Position
Horizontal / Vertical

Output Shaft Material
EN8 / Hardened Steel

Insulation Class
F Class

Backlash
Low Backlash < 10 arcmin

About Electromagnetic AC Brake Gear Motor

Helical Gear AC Brake Motor Supplier Description

We are a leading Helical Gear AC Brake Motor Supplier, offering a wide range of high-quality motors designed for industrial and material handling applications. Our motors combine robust AC motors with precision-engineered helical gearboxes and integrated electromagnetic brakes, delivering high torque, smooth operation, and reliable stopping performance.

Built for durability and efficiency, our motors are suitable for continuous and heavy-duty operations, making them ideal for cranes, hoists, conveyors, and other industrial machinery. We prioritize quality, performance, and timely delivery, ensuring that our clients receive dependable motor solutions tailored to their requirements.

Key Features:

High-quality AC brake motors with precision helical gears
Integrated electromagnetic brake for safe and precise stopping
Robust construction for long service life and reliability
Energy-efficient and low-maintenance design
Available in foot-mounted, flange-mounted, and customized configurations
Suitable for continuous and heavy-duty industrial operations

High Performance for Industrial Applications

Designed for continuous S1 duty, this gear motor offers dependable operation in scenarios demanding uninterrupted performance, such as cranes and elevators. The integration of F Class insulation, low backlash gearing, and robust mechanical construction ensures efficient and consistent torque delivery in challenging industrial environments.

Advanced Safety and Efficiency Features

The built-in AC electromagnetic shoe brake provides immediate stopping power, enhancing operational safety. Overload protection, IP55 sealing, deep groove ball bearings, and surface cooling (IC411) contribute to energy efficiency, longevity, and reliable performance, all compliant with IS 325 and IEC 60034 standards.

Flexible Mounting and Customization

Available in both foot and flange mounting versions and capable of horizontal or vertical positioning, this gear motor adapts to varied installation requirements. The standard 28 mm output shaft, multiple gearbox options, and voltage compatibility at 415V, 50Hz, make it suitable for retrofits and new system integrations.

FAQ's of Electromagnetic AC Brake Gear Motor:

Q: How does the AC electromagnetic shoe brake enhance safety in the gear motor?

A: The AC electromagnetic shoe brake provides rapid and controlled stopping of the motor, ensuring operator safety and preventing load movement in applications like hoists, cranes, and elevators. Its reliable engagement even during power failure adds an extra layer of safety to critical industrial operations.

Q: What types of industrial applications can this gear motor be used for?

A: This gear motor is designed for use in cranes, conveyors, hoists, elevators, and automation systems. Its robust construction, high starting torque, and continuous-duty capability make it suitable for various material handling and process automation environments.

Q: When should I choose the low backlash option for my application?

A: Low backlash (<10 arcmin) is essential for precise motion control, important in automation and positioning systems. It minimizes positional error, making this gear motor ideal for applications demanding accuracy and repeatability.

Q: Where can the gear motor be mounted, and what positions are supported?

A: The motor supports both horizontal and vertical mounting positions and is available in foot or flange mounting configurations. This flexibility allows it to be installed in diverse setups based on spatial and operational requirements.

Q: What is the process for maintaining the gear motor's performance over time?

A: Regular maintenance involves checking the lubrication level (synthetic oil-filled), monitoring for abnormal noise (<65 dB norm), inspecting the shoe brake operation, and ensuring the IP55 enclosure remains intact. Routine checks help ensure long-term reliability and efficiency.

Q: How does the totally enclosed fan-cooled (TEFC) design benefit the motor?

A: The TEFC design protects internal components from dust, moisture, and contaminants, which enhances the motor's durability. Coupled with IC411 surface cooling, it maintains optimal operating temperature, reducing wear and extending service life.
