Flange Mounted Helical Gear AC Brake Motor

Flange Mounted Helical Gear AC Brake Motor Specification

Rated Voltage
415 V

Features
Integral brake, high efficiency, robust design, easy installation

Voltage
415 V

Bearing Type
Heavy duty ball/roller bearing

Poles Number
2, 4, 6 poles (optional)

Torque
Up to 300 Nm (model-dependent)

Motor Type
AC Induction with brake & helical gear

Power Rating
Varies as per specification

Starting Type
Direct On Line (DOL)

Pressure
Standard atmospheric

Sealed Type
Totally Enclosed Fan Cooled (TEFC)

Standard
IS:325, IEC Standard

Horse Power
0.25 HP to 30 HP

Rated Frequency
50 Hz

Cooling Method
Fan Cooled

Efficacy
IE2/IE3

Noise Level
Below 70 dB

Current Type
AC

Ambient Temperature
-15C to +40C

Product Type
Helical Gear AC Brake Motor

Output Power
0.18 kW to 22 kW

Frequency (MHz)
50 Hz

Protect Feature
IP55

Phase
Three Phase

Speed
Variable, as per design (typically 900 - 2880 RPM)

Power
0.18 kW to 22 kW

Color
Blue

Dimension (L*W*H)
As per model (customizable)

Weight
As per rating and model

Shaft Diameter
As per model specification

Mounting Type
Flange Mounted

IP Rating
IP55

Application
Material Handling, Conveyors, Lifts, Cranes, Mixers, Automation Equipment

Lubrication
Splash Lubrication with Synthetic Oil

Duty Cycle
S1 (Continuous)

Insulation Class
Class F

Gear Ratio
5:1 to 70:1

Enclosure
Cast iron/aluminum

Thermal Protection
Optional Thermistor/PTC

Brake Type
Electromagnetic AC Disc Brake

Mounting Position
Horizontal / Vertical (as required)

About Flange Mounted Helical Gear AC Brake Motor

We bring forth for our clients a wide collection of AC Graded Brake Motors. This product is made by our skilled workmen who abide by factory mandatory requirements of all the customers. Extensively demanded for their precision dimensions, these products are assured for their seamless finishing.

Features:

High tensile strength
Rust free
Wear & tear resistant

Specifications:

Output Power: 2-6 P
Frequency: 50/60 HZ
AC Voltage: 208-230 / 240 V

Precision and Power in One Solution

This motor series is designed for applications that demand precise motion and high torque. With helical gears and integral electromagnetic AC disc brakes, it ensures smooth and controlled operation across a wide speed range (900-2880 RPM). The option of synthetic splash lubrication guarantees consistent performance and longevity under continuous S1 duty.

Robust Construction for Industrial Use

Built using durable cast iron or aluminum, the motors withstand harsh conditions with an IP55 ingress protection rating. Compliance with IS:325 and IEC standards, along with heavy-duty ball or roller bearings, enhances reliability for challenging tasks like cranes, conveyors, and lifts.

Flexible Mounting and Application Versatility

Whether your project requires horizontal or vertical mounting, or application in automation, mixers, or material handling, our flange-mounted AC brake motors adapt seamlessly. Customizable dimensions and shaft sizes ensure compatibility with various installations.

FAQ's of Flange Mounted Helical Gear AC Brake Motor:

Q: How does the flange mounted helical gear AC brake motor support continuous operation?

A: The motor is engineered for S1 (continuous) duty cycle and utilizes splash lubrication with synthetic oil, ensuring minimal wear and consistent performance during extended operations typical in material handling and automation systems.

Q: What are the benefits of the electromagnetic AC disc brake integrated in this motor?

A: The electromagnetic AC disc brake provides fast and precise stopping for improved safety and process control-essential in equipment like conveyors, lifts, and cranes-while enabling reliable holding torque when stationary.

Q: Where can this motor be installed, and does it support both horizontal and vertical mounting?

A: Designed for maximum flexibility, the motor supports both horizontal and vertical mounting positions. This allows integration into various industrial setups, including conveyors, lifts, mixers, and cranes.

Q: What protection features does the motor offer against dust, moisture, and overheating?

A: The motor's totally enclosed fan cooled (TEFC) design, IP55 rating, and optional thermistor or PTC thermal protection safeguard against dust, water ingress, and overheating during prolonged use.

Q: How customizable is the motor in terms of power rating and mounting dimensions?

A: The motor offers a wide output power range from 0.18 kW to 22 kW and customizable dimensions, ensuring it fits specific design and installation requirements. Shaft diameter and mounting flange sizes can be tailored as per the project needs.

Q: What standards of efficiency does the motor comply with, and how does this benefit operations?

A: Motors are offered in IE2 and IE3 efficiency classes, reducing energy consumption and operational costs while supporting sustainable, high-productivity industrial processes.
