Industrial NXU Gear Motor

Industrial NXU Gear Motor Specification

Gear Type
Helical Gear

Material
High-strength Cast Iron Housing

Processing Type
Precision Machined

Gear Tooth Profile
Helical Gear Teeth

Gearing Arrangement
Parallel Shaft

Direction
Bi-directional

Output Torque
Up to 8600 Nm

Rated Power
Up to 45 kW

Input Speed
1400 rpm

Output Speed
14 - 186 rpm

Voltage
380V/415V AC

Efficiency
Up to 96%

Cooling Method
Surface Cooling Fins

Protection Class
IP55

Mounting Type
Foot Mounted

Ambient Temperature Range
-15C to +45C

Lubrication Method
Oil Bath/Grease

Housing Color
Industrial Blue

Duty Cycle
Continuous (S1)

Application
Industrial Automation, Conveyors, Mixers

Noise Level
Low Noise Operation

Motor Type
Squirrel Cage Induction Motor

About Industrial NXU Gear Motor

We, Shruti Engineering, are an appreciated manufacturer, exporter and supplier of high quality Disc Brakes and Industrial Hoists. Offered range of products includes Foot Mounted Brake Motor, Disc Brake and Liner Brake.

Precision and Power

Designed with precision-machined helical gears and a robust parallel shaft arrangement, the NXU Gear Motor delivers both efficiency and high output torque. The gear motor's construction ensures minimal energy loss, smooth transmission, and exceptional lifespan, making it ideal for applications requiring sustained and reliable power output.

Enduring Industrial Performance

The NXU Gear Motor is built for continuous operation in tough environments. Its high-strength cast iron housing, epoxy powder coating for corrosion resistance, and IP55 protection class enable reliable use in industrial settings, while integrated thermal protection safeguards the motor during continuous duty.

Quiet and Efficient Operation

Operating at noise levels below 70 dB and boasting up to 96% efficiency, this gear motor ensures a peaceful workplace without compromise on performance. Surface cooling with aluminum fins and optimized lubrication maintain ideal operating temperatures, enhancing both reliability and service life.

FAQ's of Industrial NXU Gear Motor:

Q: How is the NXU Gear Motor cooled during operation?

A: The NXU Gear Motor uses a surface cooling method enhanced with aluminum fins to efficiently dissipate heat, maintaining optimal operating temperatures during continuous use.

Q: What benefits does the epoxy powder coating provide?

A: Epoxy powder coating offers strong corrosion resistance for the gear motor's cast iron housing, ensuring long-term durability and reliable performance even in harsh or humid industrial environments.

Q: When should oil bath or grease lubrication be chosen for the NXU Gear Motor?

A: Oil bath lubrication is ideal for high-speed and heavy-duty continuous operations, while grease lubrication suits moderate loads and environments where maintenance intervals are extended.

Q: Where can the NXU Gear Motor be used effectively?

A: This gear motor is suitable for conveyors, mixers, and various industrial machinery, especially in settings demanding continuous operation, high torque, and reliable, low-noise performance.

Q: What process ensures the gear teeth deliver optimal performance?

A: The gear teeth undergo precision machining, which produces helical profiles that enhance gear contact, minimize vibration, and drive up the overall efficiency and longevity of the gear motor.

Q: How does the integrated thermal overload protection work?

A: The integrated thermal overload protection monitors the motor's temperature, automatically disconnecting it if overheating is detected, thus safeguarding the motor against thermal damage during intense or prolonged use.

Q: What advantages does S1 (continuous duty) cycle provide for industrial usage?

A: S1 continuous duty cycle means the gear motor is engineered for nonstop operation under constant load, offering dependable performance suited to demanding industrial processes without the need for resting periods.
