OEM Coil with Plunger

OEM Coil with Plunger Specification

Vehicle Type
Industrial, Automotive, Railways (as applicable)

Thickness
2 mm - 5 mm (case dependent)

Pressure
Up to 6 Bar in valve application

Shape
Rectangular, Bobbin Type, Open Frame

Material
Bakelite, Copper Winding, Iron Plunger

Loading Capacity
Optimized for OEM electrical and solenoid applications

Diameter
Customizable as per requirement

Power
Typically 10-50 W

Voltage
12V / 24V / 110V / 220V AC/DC (as required)

Application
Solenoid Valves, Circuit Breakers, Electrical Equipment

Plunger Material
Magnetic Iron Core

Finish
Epoxy / Enamel Coated for Durability

Standards
OEM Specification, Made as per IS: Specifications

Operating Temperature
-20C to +80C

Insulation Class
Class B / F / H as per customer specification

Mounting
Base Plate with Bolted Fixing

Duty Cycle
Continuous / Intermittent

Coil Type
Bobbin, Moulded Bakelite, Standard Bakelite, Open Type

About OEM Coil with Plunger

Shruti offers Brake coils for Bhartia Culter HammerBCH AC operated Solenoid Brake used in for Cranes, Hoists, Machinery, Mining machineries, Marine, Machine tools, Earthmoving and wet and dry applications.

Customizable Design for Versatile Applications

Our OEM coils with plunger accommodate a range of requirements, offering options in coil type, mounting, insulation, and finish. Engineered for compatibility with industrial, automotive, and railway systems, each coil is tailored to the client's voltage, material, and dimensional preferences, ensuring reliable integration and performance across solenoid valves, electrical equipment, and circuit breakers.

Built for Durability and Efficiency

Crafted with a magnetic iron plunger, bakelite encapsulation, and a selection of epoxy or enamel coatings, these coils are optimized for demanding environments. The copper winding enables efficient power transmission, while base plate mounting ensures secure installation. Every unit not only meets OEM specifications but also adheres to IS: standards, assuring lasting operation and low maintenance.

FAQ's of OEM Coil with Plunger:

Q: How do I select the appropriate OEM coil with plunger for my application?

A: Selection is based on your application's specific requirements, including coil type (bobbin, moulded bakelite, standard bakelite, or open), voltage (12V/24V/110V/220V AC/DC), insulation class (B, F, or H), duty cycle (continuous or intermittent), and mounting method. Provide your needed dimensions, power rating, and pressure range so we can supply a coil assembly tailored to your needs.

Q: What are the typical applications and benefits of this OEM coil with plunger?

A: These assemblies are widely used in solenoid valves, circuit breakers, and other industrial, automotive, or railway electrical equipment. They deliver reliable actuation, high durability, and precise response, making them ideal for continuous or intermittent operation where dependable performance is essential.

Q: When should I opt for a specific insulation class like B, F, or H?

A: The choice of insulation class depends on your operating temperature and environment. Class B is standard for moderate temperatures, F offers higher thermal endurance, and H provides maximum protection for high-heat applications. We recommend reviewing your system's temperature range to specify the right class for optimal safety and longevity.

Q: Where can these coils be installed, and what mounting options are available?

A: Our coils are suited for installation in industrial machinery, automotive assemblies, solenoid valves, and circuit control panels. Base plate mounting with bolted fixing is standard, ensuring secure deployment in stationary or mobile equipment environments.

Q: What is the manufacturing process and how are these coils tailored to OEM specifications?

A: We manufacture each coil following strict OEM and IS: standard guidelines. The process includes precise copper winding on a bakelite bobbin or frame, encapsulation, iron plunger integration, and coating with epoxy or enamel. Your specified electrical and mechanical parameters guide customization, ensuring full compatibility with your equipment.

Q: How do the finish and material options enhance coil performance and durability?

A: Our use of bakelite, copper winding, and magnetic iron core, finished with either epoxy or enamel coating, safeguards against wear, moisture, and electrical stress. This combination boosts longevity and resilience, especially in environments subject to vibration or temperature fluctuations.
