2 HP Three Phase Motor

2 HP Three Phase Motor Specification

Current Type
AC

Sealed Type
Sealed

Poles Number
4

Starting Type
DOL

Torque
9.7 Nm

Pressure
Standard

Rated Frequency
50 Hz

Standard
IS 325/IEC 60034

Voltage
415 V

Cooling Method
Fan Cooled

Bearing Type
Ball Bearing

Features
Low Vibration, Energy Efficient, Robust Design

Efficacy
IE2

Ambient Temperature
-15C to +50C

Motor Type
Squirrel Cage Induction

Power Rating
1.5 kW

Rated Voltage
415 V

Horse Power
2 HP

Noise Level
<65 dB

Product Type
Three Phase AC Electric Motor

Output Power
2 HP (1.5 kW)

Frequency (MHz)
50 Hz

Protect Feature
Totally Enclosed Fan Cooled (TEFC)

Phase
Three Phase

Speed
1440 RPM

Power
2 HP

Color
Blue

Dimension (L*W*H)
Approx. 380 x 260 x 280 mm

Weight
24 kg

Shaft Diameter
28 mm

Mounting Type
Foot / Flange Mounted

IP Rating
IP55

Construction
Cast Iron

Insulation Class
Class F

Application
Industrial Machinery, Pumps, Fans, Compressors, Conveyors

Duty Type
S1 Continuous

Frame Size
112M

Service Factor
1.15

About 2 HP Three Phase Motor

Specifications and Performance:
Motors are continuously rated 51 duty, suitable for 415 volts -6%, 50 C/s -3%, three phase A.G. Supply with class "EIS" insulation, an ambient temperature of 40C and site attitude of up to 1000m above main sea level. All T.E.F.C. Squirrel cage motors comply with IS:325 & dimension

Rugged and Reliable Design

Constructed with high-quality cast iron, this three-phase motor ensures outstanding durability and resilience under continuous operation (Duty S1). The IP55 protection and low-noise, fan-cooled configuration guarantee operational longevity even in harsh industrial environments.

Flexible Mounting and Versatile Application

Designed for both foot and flange mounting, the motor adapts seamlessly to a wide range of industrial setups. Its compatibility with pumps, fans, compressors, conveyors, and other machinery makes it a versatile choice for manufacturers, suppliers, and exporters in multiple sectors.

Energy Efficient and Safe Operation

With IE2 energy efficiency certification, a totally enclosed fan cooled (TEFC) structure, and thermal class F insulation, this motor reduces electricity costs while providing protection from dust, moisture, and mechanical impacts-optimizing safety and performance.

FAQ's of 2 HP Three Phase Motor:

Q: How is the 2 HP Three Phase Motor typically mounted?

A: This motor offers flexibility with both foot and flange mounting options, allowing it to be installed horizontally or vertically, depending on the requirements of your machinery or industrial setup.

Q: What are the main benefits of using a totally enclosed fan cooled (TEFC) motor?

A: A TEFC motor like this one is designed to prevent dust, moisture, and other contaminants from entering the motor, ensuring quieter operation, lower maintenance needs, and extended lifespan, especially in challenging industrial environments.

Q: Where can this motor be applied in industrial settings?

A: It is ideally suited for driving industrial equipment such as pumps, fans, compressors, conveyors, and various types of machinery due to its robust construction, reliable output, and industry standard compliance.

Q: What process does the motor use to start and operate safely?

A: This motor is started via Direct-On-Line (DOL) starting, offering a simple, cost-effective process that provides full voltage to the windings for rapid, dependable start-up.

Q: What makes this motor energy efficient?

A: It features IE2 energy efficiency, reducing power consumption without compromising performance, which results in cost savings and supports environmentally friendly operations.

Q: When should I use this motor with its S1 continuous duty rating?

A: The S1 continuous duty rating means this motor is designed for uninterrupted operation at its rated load, making it perfect for applications where equipment runs for long periods without stopping.

Q: What protection does the IP55 rating provide for this motor?

A: The IP55 rating ensures the motor is protected against dust ingress and water jets from any direction, enhancing safety and operational reliability in demanding industrial environments.
