Continuous Duty Single Phase Motor

Continuous Duty Single Phase Motor Specification

Current Type
AC

Noise Level
Low Noise Operation

Features
100% Copper Winding, Energy Efficient, Low Noise, High Performance, Long Life Durability

Voltage
220-230V

Rated Frequency
50 Hz

Rated Voltage
220-230V

Standard
Insulation Class B

Horse Power
1.0 HP

Starting Type
S1 (Continuous)

Motor Type
AC Single Phase Motor

Power Rating
0.75 kW

Efficacy
Energy Efficient

Product Type
AC Single Phase Motor

Output Power
1.0 HP / 0.75 kW

Frequency (MHz)
50 Hz

Protect Feature
IP 55

Phase
Single Phase

Speed
1440 RPM

Power
1.0 HP / 0.75 kW

Color
Blue

Mounting Type
Foot Mounted (B3)

IP Rating
IP 55

Operation Condition
Continuous

Duty
S1 (Continuous)

Body Material
Heavy Duty Aluminium Body

Protection Class
IP 55

Insulation Class
B

Application
Water Pumps, Air Compressors, Blowers, Conveyors, Industrial Machinery, Agricultural Equipment, and Various Applications

About Continuous Duty Single Phase Motor

We, Shruti Engineering, are an appreciated manufacturer, exporter and supplier of high quality Disc Brakes and Industrial Hoists. Offered range of products includes Foot Mounted Brake Motor, Disc Brake and Liner Brake.

Engineered for Endurance and Performance

Designed for S1 continuous duty, this single-phase AC motor ensures unwavering performance under prolonged, constant operation. Its insulated windings and robust aluminium body promise durability, energy efficiency, and low noise, making it an ideal fit for industrial and agricultural usage alike.

Reliable Protection and Construction

With protection class IP 55, the motor withstands dust and water ingress, facilitating reliable use in tough conditions. The heavy-duty aluminium housing further reinforces durability, while Class B insulation delivers thermal stability, supporting long operational life.

Versatile Applications Across Industries

This motor powers a host of equipment including water pumps, air compressors, blowers, conveyors, and various machinery. Its high efficiency and dependable performance suit the rigorous demands of industrial, agricultural, and general mechanical processes.

FAQ's of Continuous Duty Single Phase Motor:

Q: How does the S1 Duty (Continuous) rating benefit motor operation?

A: The S1 Duty (Continuous) rating means this motor is designed for uninterrupted operation at a constant load, making it ideal for applications that require consistent, long-term performance such as industrial machines, pumps, and blowers.

Q: What protection does the IP 55 rating provide for this motor?

A: An IP 55 rating ensures that the motor is safeguarded against significant dust ingress and low-pressure water jets from any direction, allowing for reliable use in environments prone to dust and moisture.

Q: Where can this single phase motor be effectively used?

A: This motor is suitable for deployment in water pumps, air compressors, blowers, conveyors, agricultural equipment, industrial machinery, and various applications that require continuous-duty and high efficiency.

Q: What are the advantages of a heavy duty aluminium body in this motor?

A: The heavy duty aluminium body offers excellent corrosion resistance, improved heat dissipation, and a lightweight yet robust structure, contributing to the motor's long service life and efficient operation.

Q: When should I choose this motor over other types?

A: Choose this motor when you need a reliable, energy-efficient, single-phase AC motor capable of continuous operation under moderate loads, especially in scenarios where standard protection and noise levels are critical.

Q: How does the 100% copper winding affect the motor's performance?

A: 100% copper winding enhances electrical conductivity, reducing energy losses and improving overall efficiency, while also supporting longer lifespan due to superior resistance to heat and thermal stress.

Q: What mounting method is available for this motor?

A: This model is foot-mounted (B3), enabling secure and stable installation on flat surfaces, ensuring easy integration into various industrial and agricultural equipment setups.
