Packaging Machine Gear Box

Packaging Machine Gear Box Specification

Gear Type
Worm / Helical / Bevel

Material
Cast Iron / Alloy Steel

Processing Type
Precision Machined

Gear Tooth Profile
Helical / Spur

Gearing Arrangement
Parallel / Right Angle

Direction
Bidirectional

Output Torque
Up to 1200 Nm

Rated Power
0.5 HP to 15 HP

Input Speed
Up to 1500 rpm

Output Speed
10 to 300 rpm

Voltage
220V / 380V / 415V

Efficiency
Up to 95%

Protection Class
IP55

Service Factor
1.0 to 1.5

Input Shaft
Solid / Hollow

Surface Treatment
Powder Coated / Painted

Weight
Approx. 55 kg

Noise Level
Low

Cooling Method
Natural / Fan Cooled

Application
Packaging Machinery, Conveyor Systems, Industrial Equipment

Lubrication
Oil Splash / Grease

Mounting Type
Foot / Flange Mounted

About Packaging Machine Gear Box

We, Shruti Engineering, are an appreciated manufacturer, exporter and supplier of high quality Disc Brakes and Industrial Hoists. Offered range of products includes Foot Mounted Brake Motor, Disc Brake and Liner Brake.

Engineered Reliability and Flexibility

This gear box is crafted for diverse mounting needs and operates with minimal noise, ensuring efficient usage in environments where reliability is paramount. IP55 protection, quality surface treatments, and robust construction from cast iron or alloy steel ensure longevity even under challenging conditions. The bidirectional capability and multiple input/output configurations make it extremely versatile for a wide spectrum of conveyor and packaging systems.

Precision and Performance

Utilizing precision machining and advanced gear tooth profiles-helical or spur-this gear box delivers up to 95% efficiency and smooth operation at various speeds. The range of rated power and torque output supports custom requirements in heavy and light industrial setups. Natural or fan cooling methods, in combination with quality lubrication, guarantee that the gear box maintains peak performance during extended operations.

FAQ's of Packaging Machine Gear Box:

Q: How is the Packaging Machine Gear Box installed and what mounting options are available?

A: The gear box can be easily installed using either foot or flange mounting types, catering to a variety of layout configurations in packaging, conveyor, or industrial machinery. This provides adaptability based on your machine design and space requirements.

Q: What are the lubrication and cooling options, and how do they benefit the gear box?

A: Lubrication can be chosen between oil splash and grease, depending on maintenance preferences and operating conditions. Cooling can be either natural or fan-assisted, both ensuring the gear box runs efficiently and maintains low temperatures, which extends service life.

Q: When should I consider using this gear box for my industrial application?

A: If your operation requires reliable power transmission for packaging machinery, conveyors, or other equipment-with high efficiency, robust protection, and low noise-the gear box's features make it suitable for use in new installations or as a replacement in existing systems.

Q: Where can the Packaging Machine Gear Box be utilized effectively?

A: It is ideally used in industrial environments such as packaging plants, conveyor-driven systems, and other machinery that demands consistent torque and durable construction. Its IP55 protection class also makes it suitable for areas exposed to dust or water splashes.

Q: What is the process of surface treatment, and how does it protect the gear box?

A: Each gear box undergoes either powder coating or painting, providing a durable exterior that resists corrosion and wear. This enhances the longevity of the product and helps maintain its performance in harsh industrial settings.

Q: How does the gear box accommodate different input and output setups?

A: The gear box supports both solid and hollow input shafts, a bidirectional function, and multiple gear arrangements. This flexibility allows for seamless integration into a range of mechanical systems, adapting to your specific operational needs.

Q: What are the key benefits of choosing this gear box for packaging machinery?

A: Key benefits include high efficiency (up to 95%), low noise, durable materials, adaptable mounting and cooling options, and reliable operation with a broad range of speed and torque capabilities. These factors contribute to lower maintenance and consistent machine uptime.
