Packaging Machine Gear Motor

Packaging Machine Gear Motor Specification

Efficacy
High Efficiency

Power Rating
As per model - 0.18kW to 3.7kW

Horse Power
0.25 HP to 5 HP

Standard
IEC/IS/EN (International standards, model specific)

Rated Frequency
50/60 Hz

Pressure
N/A (not typically pressure rated)

Cooling Method
Air Cooled (Fan cooled)

Poles Number
2/4/6 poles (as per design)

Motor Type
Induction Gear Motor

Bearing Type
Double sealed ball bearings

Ambient Temperature
-15C to 45C

Rated Voltage
220/380/415 V

Torque
Max. up to 350 Nm (depending on gear ratio)

Current Type
AC

Starting Type
Direct On Line (DOL)

Sealed Type
Sealed against dust and moisture (IP55/IP65)

Noise Level
<65 dB (low noise design)

Voltage
220V/380V/415V (as per requirement)

Features
Compact design, high starting torque, maintenance free, corrosion resistant housing

Product Type
Packaging Machine Gear Motor

Output Power
0.25 HP to 5 HP (typically varies by model)

Frequency (MHz)
50/60 Hz (standard industrial motor frequency)

Protect Feature
Totally Enclosed Fan Cooled (TEFC), Overload protection

Phase
Single Phase/Three Phase (as per requirement)

Speed
15 to 300 RPM (adjustable with gear ratio)

Power
0.18 kW to 3.7 kW

Color
Blue and Grey

Dimension (L*W*H)
Custom, varies by model (approx. 350 x 180 x 150 mm)

Weight
8 kg to 35 kg (depending on size and gear ratio)

Shaft Diameter
18 mm to 42 mm (varies by model)

Mounting Type
Flange Mounted/Foot Mounted

IP Rating
IP55/IP65

Gearbox Type
Worm Gear / Helical Gear (options available)

Application
Ideal for automation, conveyor, and packaging machinery

Vibration Level
Low (Built as per IEC 60034-14)

Lubrication Type
Permanent grease lubrication / Oil bath

Ambient Humidity
90% RH (non-condensing)

Duty Cycle
S1 (Continuous Duty)

Insulation Class
Class F / Class H

Material
Aluminium alloy body with steel gears

About Packaging Machine Gear Motor

The SW reducer, which complements the Motovario NMRV gear reducer, has a shaft height between 30 and 110 mm (Baugren 030 bis 105) and a compact round smooth body casing design that reduces the space as much as possible. For better reliability and compatibility/effectiveness of supply, the gearing, the bearings, the motor flange and the accessories are those of the NMRV

Versatile Gearbox Options

Choose between worm gear or helical gear configurations to match your specific operation needs. The modular design facilitates easy integration into various types of packaging and conveyor systems, providing adaptable solutions for different torque and speed requirements.

Engineered for Durability and Low Maintenance

With an aluminium alloy body, steel gears, and double-sealed ball bearings, this gear motor is built for enduring harsh industrial conditions. Permanent grease lubrication or oil bath ensures a virtually maintenance-free service life, while IP55/IP65 sealing provides extra protection against dust and moisture.

Superior Performance and Efficiency

Designed with high starting torque, robust overload protection, and energy-efficient operation, this gear motor delivers reliable, continuous performance even in environments with high ambient humidity (up to 90% RH). Suitable for both single and three-phase power systems, it's an ideal fit for manufacturers looking to optimize throughput and minimize downtime.

FAQ's of Packaging Machine Gear Motor:

Q: How can I determine whether to select a worm gear or helical gear type for my packaging machine?

A: The choice between worm gear and helical gear depends on your application's requirements. Worm gears are preferred for high reduction ratios and quieter operation, while helical gears offer higher efficiency and better load capacity. Consult your packaging process and torque needs for optimal selection.

Q: What are the benefits of the aluminium alloy body and steel gears in this gear motor?

A: The aluminium alloy body ensures a lightweight yet corrosion-resistant structure, while the steel gears provide superior strength and durability. This combination results in a robust motor suitable for harsh and demanding packaging and conveyor environments.

Q: When is maintenance required for this gear motor, considering its lubrication system?

A: The gear motor is designed to be maintenance-free due to its permanent grease lubrication or oil bath system. Under normal operating conditions, regular maintenance is minimal-typically, only periodic inspection is recommended to ensure ongoing performance.

Q: Where should this gear motor be installed for optimal performance and protection?

A: Install the gear motor in environments within the specified ambient temperature range of -15C to 45C and ambient humidity up to 90% RH (non-condensing). The IP55/IP65 sealed design protects the motor against dust and moisture, making it suitable for most industrial indoor locations.

Q: What is the process for mounting the gear motor in packaging machinery?

A: The gear motor supports both flange and foot mounting configurations, making installation flexible. Secure the motor following the manufacturer's guidelines, ensuring precise alignment and correct torque settings, to maintain performance and prolong lifespan.

Q: How does this gear motor benefit packaging machine operations?

A: This gear motor offers high starting torque, energy efficiency, low noise (<65 dB), and minimal vibration. It helps ensure precise, continuous automated movements in packaging applications, reduces maintenance downtime, and delivers reliable performance even in challenging conditions.

Q: What safety and protection features are included with the gear motor?

A: The motor features overload protection, Totally Enclosed Fan Cooled (TEFC) construction, and complies with international standards (IEC/IS/EN). These features safeguard the motor and connected equipment, prolonging service life and ensuring operator safety.
