Signal Phase Electromagnetic AC Brake

Signal Phase Electromagnetic AC Brake Specification

Color
Blue

Usage
Brake Motors

Size
Standard

Material
Cast Iron

Voltage
220 Volt (v)

Signal Phase Electromagnetic AC Brake Trade Information

Minimum Order Quantity
1 Unit

Payment Terms
Cash in Advance (CID)

Supply Ability
500 Units Per Month

Delivery Time
2-10 Days

Main Domestic Market
All India

About Signal Phase Electromagnetic AC Brake

Our firm is dedicated towards meeting the requirements of clients with an unmatched range of Electromagnetic Disc Brakes. These brakes help to slow or stop motion of the wheels by using electromagnetic force, thus installed in earth moving machines, trucks and other heavy vehicles. These Electromagnetic Disc Brakes are designed under the vigilance of expert professionals by using top quality materials, in complete adherence with international quality standards. Our clients can avail these brakes from us at reasonable prices.

Features:

Corrosion resistance
Negligible maintenance
Finely finished body

Further Details:

Electro Magnetic Disc Brake

The Electromagnetic Disc Brake, Magnetic Brakes offered by us has a high class insulation coil, a good quality liner plate and a thick liner. The brake is developed specially to provide maximum benefit and is termed as a rugged unit. These brakes are used extensively in industrial vehicles, heavy vehicles and are fabricated according to global standards and specifications. Fail Safe Brake for Brake Motors:

Brake Motor is combination of three phase Squirrel Cage Induction Motor with Electro-Magnetic Disc Brake A.C. When power is switched off with ordinary Motor, the rotating parts will stopped after some time but if Brake Motor is used rotating mass will stop instantaneously. All Brakes are mounted at non-driving end of Motor, Braking disc is mounted directly on motor shaft. Brakes arc directly acting, no lever or links are required. Friction Liner Plate is only wearing part and this is easily replaceable.
