Wire Rope Hoist for Mining

Wire Rope Hoist for Mining Specification

Trolley
Motorized

Rotation Speed
1440 RPM

Frequency
50 Hz

Capacity
1 Ton to 10 Ton

Lifting Speed
3 to 8 m/min

Hook
Heavy Duty Forged Hook

Condition
New

Lift Speed
Variable (as per model)

Max. Lifting Height
6 to 30 meters

Max. Lifting Weight
10 Tons

Sling Type
Wire Rope

Power Source
Electric

Power
3 kW to 24 kW

Voltage
415V AC

Application
Mining, Construction, Heavy Industry

Insulation Class
Class F

Duty Cycle
Heavy Duty, 60% ED

Material
High-Strength Alloy Steel Frame

Brake Type
Electromagnetic Brake System

Control Method
Pendant/Remote Control

Ambient Temperature Range
-20C to +55C

Protection Grade
IP54/55

Wire Rope Hoist for Mining About

A hoist is a device used for lifting or lowering a load by means of a drum or lift-wheel around which rope or chain wraps. It may be manually operated, electrically or pneumatically driven and may use chain, fiber or wire rope as its lifting medium.

Advanced Safety and Durability

Built with a high-strength alloy steel frame and protection rating of IP54/55, this wire rope hoist guarantees operational safety in challenging industrial environments. The electromagnetic brake system and Class F insulation further enhance reliability and longevity, ensuring secure handling of loads up to 10 tons.

Efficient and Versatile Performance

Offering lifting speeds from 3 to 8 m/min and motorized trolleys, the hoist adapts to varied jobsite demands. Its heavy-duty forged hook and robust construction allow for hassle-free use in mining, construction, and heavy industry applications. Remote and pendant controls provide flexible operation, even from a distance.

FAQ's of Wire Rope Hoist for Mining:

Q: How does the wire rope hoist ensure safety during heavy lifting operations?

A: The hoist incorporates an electromagnetic brake system and is constructed with a high-strength alloy steel frame, ensuring stable load handling. Its heavy-duty forged hook and protection grade of IP54/55 also help safeguard the equipment and operators in harsh working environments.

Q: What are the benefits of using a wire rope hoist in mining and heavy industry settings?

A: This wire rope hoist offers high durability, excellent load capacity (1 to 10 tons), and variable lifting speeds, making it ideal for demanding applications. The motorized trolley and remote control options increase efficiency and reduce manual labor, ultimately improving operational productivity.

Q: When should I choose a wire rope hoist with a heavy-duty forged hook?

A: For applications requiring the safe and reliable lifting of heavy materials, such as mining or heavy construction tasks, a wire rope hoist with a heavy-duty forged hook is essential. It provides the strength and robustness necessary to handle large loads securely.

Q: Where can this wire rope hoist be installed or used?

A: This hoist is suitable for installation in mines, construction sites, factories, and warehouses. Its protective features and insulating class enable it to operate effectively in environments with dust and moisture, and within temperatures from -20C to +55C.

Q: What is the process of operating the wire rope hoist?

A: Operation can be managed using either a pendant or remote control, allowing the user to control lifting, lowering, and trolley movement safely from a distance. The electromagnetic brake ensures the load remains securely suspended when not in motion.

Q: How does the variable lifting speed feature benefit users?

A: The ability to adjust lifting speeds between 3 to 8 m/min enhances operational versatility. It allows operators to select optimal speeds depending on the specific load and conditions, maximizing safety and efficiency during material handling tasks.
