Coil with Plunger

Coil with Plunger Specification

Vehicle Type
Industrial machines, not specific to automotive use

Thickness
Coil enclosure typically 5-8 mm

Shape
Rectangular, square (as per type: bobbin, moulded, standard bakelite)

Pressure
Not directly applicable; acts as part of electromagnetic actuator

Material
Bakelite, Copper (coil winding), Steel (plunger)

Loading Capacity
Customizable as per application

Diameter
Varies by coil type, typically 20-60 mm

Power
10W - 50W, depending on specification

Voltage
12V, 24V, 110V, 230V AC/DC (as per order)

Application
Electromagnetic operation in machinery, solenoid applications, industrial automation

Customization
Fully customizable in voltage, size, and mounting as per requirement

Operating Frequency
50/60 Hz for AC variants

Insulation Class
Class B / F (on request)

Coil Type
Bobbin Type, Moulded Bakelite, Standard Bakelite, Open Type

Quality
Premium quality, reliable performance

Mounting
Base plate mounting with bolts

Coil with Plunger About

Brake coils for Bhartia Culter HammerBCH AC operated Solenoid Brake used in for Cranes, Hoists, Machinery, Mining machineries, Marine, Machine tools, Earthmoving and wet and dry applications.

Shruti Engineering are the very highly acclaimed organization in this sector, engaged in manufacturing and supplying an exclusive range of AC Solenoid Magnetic Brake. These products are gaining appreciation from every where in the world for its unmatched quality and low maintenance. Our offered product range is manufactured using fine grade raw materials and modern technology and it is designed as per the specifications of our distinguished customers.

Versatile Electromagnetic Solution

Our coils with plungers are engineered for seamless integration into a wide range of industrial machinery and automation systems. Manufactured using Bakelite for durability, with flexible configurations like bobbin, moulded, or open types, these products are designed for applications demanding high reliability and customization. Their adaptable specifications ensure compatibility for both standard and unique operational needs.

Comprehensive Customization Options

Each coil with plunger can be tailored to match your specific requirements. From voltage and power output to mounting styles and shapes, our solutions accommodate diverse project demands. Choose from a variety of enclosure thickness, diameters, and insulation classes for optimal performance, making them ideal for OEMs and automation integrators.

FAQ's of Coil with Plunger:

Q: How do I select the appropriate coil with plunger for my application?

A: To select the right model, consider your required voltage, mounting type, coil shape, operating frequency, and application needs. We offer full customization in size, power range, and mounting, ensuring compatibility with your electromagnetic or automation equipment.

Q: What is the primary benefit of using bakelite-based coils for industrial machinery?

A: Bakelite offers excellent electrical insulation and heat resistance, enhancing safety and durability in demanding operational environments. This makes our coils ideal for consistent performance and longevity in industrial applications.

Q: When should I choose a Class B or Class F insulation coil?

A: Choose Class B insulation for environments with standard temperature exposure or Class F for applications requiring higher thermal resistance. Specify your insulation preference during order placement to suit your operating conditions.

Q: Where can these coils with plungers be installed?

A: These coils are typically base plate mounted with bolts, suitable for installation in solenoids, actuators, and industrial automation machinery. Their customizable design allows integration across various OEM systems and automated equipment.

Q: What customization options are available for these coils?

A: You can fully customize voltage (12V, 24V, 110V, 230V AC/DC), coil dimensions, power (10W-50W), and mounting configurations. Enclosure thickness, diameter, and coil type are also adjustable per your project's requirements.

Q: How is the coil with plunger used in electromagnetic operations?

A: The coil, energized by electrical current, creates a magnetic field that actuates the plunger mechanism. This action is essential in solenoids, machine automation, and other electromagnetic actuation processes commonly utilized in industrial systems.

Q: What distinguishes your coil with plunger in terms of quality?

A: We use premium materials such as Bakelite, copper winding, and steel plungers. Combined with rigorous manufacturing standards, this ensures outstanding reliability, consistent performance, and long service life even in intensive industrial applications.
