NMRV Gear Box for Packaging Machine

NMRV Gear Box for Packaging Machine Specification

Gear Type
Worm and Wheel

Material
Aluminum Alloy Housing, High Strength Cast Iron

Processing Type
Precision Machining

Gear Tooth Profile
Worm Gear

Gearing Arrangement
Right Angle

Direction
Bidirectional

Output Torque
Up to 350 Nm (Model dependent)

Rated Power
Up to 7.5 kW

Input Speed
1400 rpm

Output Speed
14-186 rpm (Depends on Ratio)

Voltage
220V/380V/415V (Motor dependent)

Efficiency
Up to 94%

Protection Grade
IP55 (Motor dependent)

Housing Color
RAL 9022 Grey/Silver

Input Shaft Diameter
Varies by Model (14mm-35mm)

Noise Level
Low Noise Operation

Application
Packaging Machine, Conveyor Systems, Automation

Sealing
Precision Oil Seals Installed

Output Shaft Type
Hollow Shaft/Single or Double Output

Cooling Type
Natural Air Cooled

Gear Ratio Range
7.5:1 - 100:1

Operation Temperature
-10C to +40C

Lubrication
Synthetic Oil

Mounting Type
Flange/Foot Mounted

About NMRV Gear Box for Packaging Machine

Three PhasePower0.5 HP TO 20 HPBrandSMISpeed30 RPM TO 200 RPMVoltage440Minimum Order Quantity2 Piece

Product Description:

Integral Brake Motors are suitable for various industrial application like Textile, Machine
Tools, Hoists, Cranes, Lifts etc., where instantaneous stopping of the driven equipment is
demanded.

Motors are fitted with Electro Mgnetic Normally on brakes.

The electro-magnetic DC brake is mounted on the non-driving end of the motor. The cooling
fan is mounted after the brake for better thermal dissipation and cooling of the brake also.

Motor connection leads and brake coil leads are terminated in a single terminal box for
easy connection, Rectifiers are supplied in loose condition and Manual release is provided

Outstanding Performance for Packaging Automation

Engineered specifically for packaging machinery and conveyor systems, the NMRV Gear Box boasts reliable efficiency, low noise operation, and a robust, compact build. Its synthetic oil lubrication and precision engineering ensure extended service life and minimal maintenance requirements. The IP55 protection grade (motor dependent) makes it adaptable to a range of industrial environments, providing trusted performance where precision and durability are critical.

Versatile Mounting and Output Options

With the choice of flange or foot mounting and a range of input shafts (14mm-35mm), this gear box adapts to various system layouts. Output can be configured as a hollow shaft, single, or double output, catering to specific application needs. Its high-torque capabilities, variable gear ratios, and compatibility with multiple voltages make it an exceptional solution for diverse industrial automation projects.

FAQ's of NMRV Gear Box for Packaging Machine:

Q: How does the NMRV Gear Box benefit packaging machine applications?

A: The NMRV Gear Box provides high efficiency, low noise levels, and robust torque output, enhancing the performance and reliability of packaging machines. Its precision machining and strong materials ensure stability, while flexibility in mounting and output options allow for seamless integration into existing machinery.

Q: What is the recommended lubrication for the NMRV Gear Box?

A: The gear box uses high-quality synthetic oil for lubrication. This provides excellent thermal stability and extends maintenance intervals, contributing to reliable, long-term operation even under heavy loads within packaging and automation systems.

Q: When should the synthetic oil be changed in the gear box?

A: It is advised to follow the manufacturer's maintenance guidelines, typically involving oil inspection every 3,000 to 5,000 hours of operation. Replace the synthetic oil as needed to maintain optimal performance and prevent premature wear.

Q: Where can the NMRV Gear Box be installed?

A: Due to its IP55 protection grade (motor dependent), natural air-cooling, and robust sealing, the gear box can be installed in various industrial settings such as packaging plants, automated conveyor systems, and environments requiring efficient, dust-resistant gearing solutions.

Q: What is the process for selecting the suitable NMRV Gear Box model?

A: Selection depends on application-specific requirements: desired torque, output speed, input power, mounting preference, and shaft specifications. By matching these parameters, users ensure optimal gear box performance and longevity.

Q: How does the NMRV Gear Box ensure low noise operation?

A: The gear box is engineered with precision oil seals, accurate machining, and a worm gear profile, minimizing vibration and noise during operation. These features make it ideal for noise-sensitive environments, like packaging facilities.

Q: What are the main advantages of using a NMRV Gear Box in automation systems?

A: Its high efficiency, broad gear ratio range, durable construction, and flexible mounting options deliver reliable power transmission. The unit's adaptability and easy integration support efficient automation in packaging lines and conveyor applications.
