THRUSTER BRAKE Specification

Features
High reliability, Low maintenance, Fast response, Rugged construction

Mounting Type
Base Mounted

Usage & Applications
EOT Cranes, Hoists, Conveyors, Lifts, Winches, Elevators

Noise Level
Low

Part Type
Brake Assembly

Brake Type
Electro Hydraulic Thruster Brake

Size
Standard/Custom Sizes Available

Material
Mild Steel / Cast Iron

Pattern Material
High Quality Friction Lining

Surface Finish
Powder Coated & Painted

Standard
Conforms to IS and International Standards

Corrosion Protection
Yes, with treated & coated surfaces

Brake Shoe Adjustment
Manual with locking arrangement

Ambient Temperature Range
-20C to +50C

Holding Torque Range
6 Nm to 1200 Nm

Brake Drum Diameter
100 mm to 600 mm (as per model)

Release Time
<0.2 seconds

Insulation Class
Class F or higher

Spring Type
Heavy-Duty Compression Spring

Operation Voltage
415V AC 3-Phase (Other voltages on request)

About THRUSTER BRAKE

Electro Hydraulic Thruster Brake Supplier in Indore Description

We are a trusted and leading Supplier of Electro Hydraulic Thruster Brakes in Indore, providing high-performance industrial braking solutions for hoists, cranes, and heavy-duty material handling systems. Our thruster brakes are designed for smooth, reliable, and fail-safe operation, ensuring maximum safety and efficiency in demanding industrial environments.

Built with robust cast iron/steel construction and powered by advanced electro-hydraulic thrust technology, these brakes deliver consistent braking force, zero shock load, and long service life. As a dependable supplier in Indore, we offer a complete range of models suitable for small, medium, and heavy-load machinery.

Versatile Application and Customization

This thruster brake is designed to accommodate a wide range of machinery. Available in standard or custom sizes, it fits brake drums from 100 mm to 600 mm and delivers holding torque from 6 Nm to 1200 Nm. Material options such as mild steel or cast iron, paired with high-quality friction linings, ensure optimal performance in various industrial environments.

Exceptional Durability and Protection

Equipped with powder-coated and painted surfaces along with corrosion-protected components, this brake assembly offers longevity even in harsh conditions. The insulation class F or higher guarantees electrical safety, while the rugged construction supports continuous, reliable operation under ambient temperatures from -20C to +50C.

FAQ's of THRUSTER BRAKE:

Q: How does the electro hydraulic thruster brake operate?

A: This brake uses an electro hydraulic thruster to compress a heavy-duty spring, releasing the brake. When power is cut, the spring engages, applying braking force to halt the machinery effectively and rapidly.

Q: What types of equipment are suitable for this thruster brake?

A: The brake is ideal for EOT cranes, hoists, conveyors, lifts, winches, and elevators, wherever robust, quick-response stopping power and safety are essential.

Q: When is manual brake shoe adjustment required, and how is it done?

A: Manual adjustment is recommended during routine maintenance or wear compensation. The adjustment process involves repositioning the brake shoe and securing it using the provided locking arrangement to maintain optimal braking performance.

Q: Where can customization be applied to this brake assembly?

A: Customization is available for size, operation voltage, and material based on specific application requirements. Both standard and tailor-made sizes ensure a precise fit and optimal operation for various installations.

Q: What benefits does corrosion protection and treated surfaces offer?

A: Corrosion-protected, powder-coated, and painted surfaces safeguard the assembly against rust and environmental wear, significantly extending its service life and maintaining reliable performance in challenging conditions.

Q: What standards and safety regulations does this brake comply with?

A: The brake conforms to IS and recognized international standards, ensuring reliable safety, performance, and compatibility for global usage in industrial applications.
