ELECTRO HYDRAULIC THRUSTER

535 MODEL THRUSTER

535 MODEL THRUSTER Specification

Pressure
250 Bar

Thickness
8 mm

Shape
Cylindrical

Material
Mild Steel (MS)

Loading Capacity
500 to 1200 kg

Diameter
200 mm

Power
5 HP

Voltage
415 V

Application
Industrial Hydraulic Systems

Weight
75 kg

Mounting Type
Top Flange Mounting

Surface Finish
Powder Coated

Cooling Type
Air-Cooled

Motor Type
IE2 Efficient Motor

Model Number
535 MODEL THRUSTER

Phase
Three Phase

Flow Rate
60 LPM

About 535 MODEL THRUSTER

The Electro Hydraulic Thruster for EOT Crane is a precision-engineered braking solution designed to provide smooth, reliable, and fail-safe operation for Electric Overhead Traveling (EOT) cranes. This thruster converts electrical energy into hydraulic force to engage or release the cranes brake efficiently, ensuring controlled movement and secure load handling.

Constructed with a robust frame, high-quality brake linings, and a high-performance electro-hydraulic thruster, this device guarantees instantaneous braking in case of power failure, preventing accidental load movement. When power is restored, the thruster releases the brake smoothly, enabling precise starts and stops for crane operations.

This system is ideal for heavy-duty lifting applications where safety, reliability, and consistent performance are essential.

Powerful Performance for Heavy-Duty Applications

Engineered to excel in industrial hydraulic systems, the 535 MODEL THRUSTER delivers consistent force and controlled movement. With a substantial loading capacity and a 5 HP motor, it is well-suited for rigorous applications requiring reliability and strength under demanding conditions.

Efficient Design and Reliable Operation

Fitted with an IE2 efficient motor and air-cooling mechanism, this thruster consumes energy judiciously while ensuring optimal performance. The powder-coated mild steel construction not only enhances durability but also offers increased resistance to corrosion, thus extending the product's lifespan.

FAQ's of 535 MODEL THRUSTER:

Q: How is the 535 MODEL THRUSTER installed in industrial setups?

A: The thruster is designed with a top flange mounting for straightforward and secure installation onto compatible hydraulic system structures, ensuring stable and reliable operation in industrial environments.

Q: What are the main benefits of using the 535 MODEL THRUSTER in hydraulic systems?

A: This model offers efficient power delivery, reliable performance under high pressure (up to 250 Bar), robust construction, and energy savings thanks to its IE2 motor, making it ideal for demanding industrial applications.

Q: When should the 535 MODEL THRUSTER be used?

A: It is best utilized in situations requiring substantial force, consistent pressure (250 Bar), and dependable operation for loads ranging from 500 to 1200 kg, typically in heavy-duty hydraulic processes.

Q: Where can the 535 MODEL THRUSTER be applied?

A: The thruster is applicable in a wide range of industrial hydraulic systems, including manufacturing plants, heavy machinery, and material handling equipment, wherever precise movement and high load capacity are needed.

Q: What is the process to maintain the 535 MODEL THRUSTER for optimal performance?

A: Regularly inspect the air-cooling vents, ensure the flange mounting remains secure, monitor the flow rate, and check for surface wear on the powder-coated mild steel to maintain top performance.

Q: How does its IE2 efficient motor contribute to overall system efficiency?

A: The IE2 efficient motor minimizes energy consumption while delivering consistent power, thereby reducing operational costs and enhancing the sustainability of the hydraulic system.
