Single Phase Electromagnetic Brake Motor

Single Phase Electromagnetic Brake Motor Specification

Sealed Type
Totally Enclosed Fan Cooled (TEFC)

Power Rating
0.375 kW

Starting Type
Direct On Line (DOL)

Features
Electromagnetic Brake, High Efficiency, Rugged Construction

Cooling Method
Fan Cooled

Standard
IS:325, IEC

Voltage
230 V

Current Type
AC

Motor Type
Single Phase Electromagnetic Brake Motor

Rated Voltage
230 V

Efficacy
S1 (Continuous)

Horse Power
0.5 HP

Rated Frequency
50 Hz

Product Type
AC Single Phase Motor

Output Power
0.5 HP / 0.375 kW

Frequency (MHz)
50 Hz

Protect Feature
IP55

Phase
Single Phase

Speed
1440 RPM

Power
0.375 kW

Color
Blue

Mounting Type
Foot Mounted

IP Rating
IP55

Protection
IP55

Manufacturing Date
Mar 2024

Duty
S1 (Continuous)

Motor Number
SE/54-25/51001

Current
6.40 A

Insulation Class
Class F

About Single Phase Electromagnetic Brake Motor

Shruti Engineering

We, Shruti Engineering, are an appreciated manufacturer, exporter and supplier of high quality Disc Brakes and Industrial Hoists. Offered range of products includes Foot Mounted Brake Motor, Disc Brake and Liner Brake.

Reliable Operation & Enhanced Safety

The electromagnetic brake ensures swift and secure stopping, preventing load drift and improving operator safety. The IP55 rating and TEFC construction protect the motor from dust, water, and harsh environmental conditions, making it suitable for challenging industrial environments where dependability is essential.

Continuous Duty Performance

With S1 (Continuous) duty classification and Class F insulation, this motor is built for long hours of uninterrupted operation. Its direct-on-line starting and foot-mounted design facilitate simple installation and consistent performance, enhancing productivity while minimizing maintenance needs.

Energy Efficiency & Rugged Construction

Engineered for high efficiency and built to last, the motor features a robust construction that adheres to national and international standards (IS:325, IEC). Its cooling system ensures optimal temperature control, increasing motor lifespan and maximizing energy savings for your operations.

FAQ's of Single Phase Electromagnetic Brake Motor:

Q: How does the electromagnetic brake function in this single phase motor?

A: The integrated electromagnetic brake utilizes an electrical current to generate magnetic force, rapidly stopping the motor shaft when power supply is interrupted. This ensures immediate, precise halting for enhanced safety and accurate load placement in industrial applications.

Q: What are the ideal usage scenarios for this motor?

A: This motor is best suited for machinery requiring quick and controlled stopping, such as conveyors, hoists, material handling equipment, and automated industrial systems. Its S1 duty (continuous operation) makes it excellent for applications needing uninterrupted, reliable performance.

Q: When should maintenance be performed on this brake motor?

A: Due to its totally enclosed fan-cooled (TEFC) design and robust IP55 protection, the motor requires minimal maintenance. However, periodic inspections (every 6-12 months) are recommended to check the fan, brake assembly, and electrical connections for optimal operation and longevity.

Q: Where can this single phase electromagnetic brake motor be installed?

A: Thanks to its IP55 rating and rugged construction, the motor is suitable for both indoor and outdoor settings with moderate exposure to dust and water. It is commonly foot-mounted in industrial plants, warehouses, workshops, and environments where reliable braking is necessary.

Q: What is the process for connecting and starting the motor?

A: This motor supports direct-on-line (DOL) starting; simply connect it to a stable 230V AC supply as per the provided wiring diagram. Ensure proper earthing and utilize appropriate protection devices for safe operation. The foot-mounting base allows straightforward installation on standard frames or flat surfaces.

Q: What are the main benefits of choosing this model?

A: Key benefits include high operational efficiency, robust brake performance, enhanced safety features, durability under continuous operation, and compliance with IS:325 and IEC standards. These features collectively help reduce maintenance costs and downtime, offering superior value for industrial users.
