Three Phase Motor Supplier

Three Phase Motor Supplier Specification

Pressure
Normal Atmospheric Pressure

Rated Voltage
380V / 415V

Power Rating
As per Model (up to 7.5 kW standard)

Rated Frequency
50 Hz / 60 Hz

Current Type
AC

Ambient Temperature
-15C to +50C

Sealed Type
Sealed (TEFC)

Torque
Rated torque as per output (e.g. 2.5 Nm - 40 Nm)

Bearing Type
Ball Bearing

Voltage
380V / 415V / 440V

Motor Type
Induction Motor

Efficacy
IE2 / IE3

Starting Type
DOL / Star-Delta

Horse Power
0.5 HP to 10 HP

Standard
Conforms to IS:325 / IEC 60034-1

Poles Number
2, 4, 6, 8 Poles

Features
Low Maintenance, High Starting Torque, Robust Construction

Cooling Method
Fan Cooled

Noise Level
< 70 dB

Product Type
Electric Three Phase Motor

Output Power
Varies (typically 0.5 HP to 10 HP or customized as required)

Frequency (MHz)
50 Hz / 60 Hz

Protect Feature
Totally Enclosed Fan Cooled (TEFC), Overload Protection

Phase
Three Phase

Speed
1440 - 2880 RPM (based on poles)

Power
0.37 kW to 7.5 kW (Standard Range)

Color
Blue

Dimension (L*W*H)
Depends on Power Rating (Standard Industrial Sizes)

Weight
Varies with Model (Approx. 15 kg - 70 kg)

Shaft Diameter
Standard as per Power (e.g. 24mm, 28mm, etc.)

Mounting Type
Foot / Flange / Face Mounting

IP Rating
IP55

Vibration Level
Meets IS/IEC Standards

Efficiency
Up to 90% (Depending on Model)

Lubrication
Pre-lubricated Bearings

Application
Pumps, Compressors, Blowers, Industrial Machinery

Enclosure Type
TEFC (Totally Enclosed Fan Cooled)

Direction of Rotation
Both (CW/CCW)

Thermal Protection
Thermistors (optional)

Rotor Type
Squirrel Cage

Duty Type
S1 (Continuous Duty)

Rated Slip
1-5% depending on design

Insulation Class
Class F

Base Frame Size
Standardized as per rating

Housing Material
Cast Iron / Aluminium

About Three Phase Motor Supplier

We are manufacture, exporter and supplier of brake motor. Basically Brake motor is combination of brake and motor. Our clients can avail from us a wide collection of best quality Brake Motors. These products are appreciated for its optimum performance and excellent quality. Raw material for these products sourced from repudiated vendors, the offered motors are well known among the client and can be availed from us in standard sizes according to the requirements of individual. Highly demanded for its special features, this product is offered at budget friendly prices by us.

Versatile Industrial Applications

These three phase motors are engineered to serve in a multitude of industrial roles, from driving pumps and compressors to powering blowers and machinery. With flexible mounting options and compatibility with various setup requirements, they deliver reliable performance in every environment.

Built for Durability and Efficiency

Constructed with high-grade cast iron or aluminium, our motors feature pre-lubricated ball bearings and sealed TEFC enclosures, ensuring longevity even in tough conditions. Their high starting torque and up to 90% efficiency meet the most demanding industrial standards, resulting in significant energy savings.

Seamless Operation and Safety

Our motors support continuous duty (S1) operation and offer optional thermistor-based thermal protection. With standardized frames, low vibration, and overload protection, these motors guarantee smooth, safe, and dependable use for long operational cycles in diverse applications.

FAQ's of Three Phase Motor Supplier:

Q: How do I select the right three phase motor for my industrial application?

A: To choose the right motor, consider the required output power (typically 0.5 HP to 10 HP), mounting type (foot, flange, or face), and operating environment. Check compatibility with your voltage (380V-440V), frequency (50/60 Hz), and application (pumps, compressors, blowers). Contact us with your specific requirements for a customized solution.

Q: What benefits do TEFC (Totally Enclosed Fan Cooled) enclosures provide?

A: TEFC enclosures protect the motor from dust, moisture, and other contaminants. This design facilitates reliable operation in harsh industrial conditions, reduces maintenance needs, and extends motor lifespan, making them suitable for continuous duty (S1).

Q: When is thermal protection with thermistors recommended?

A: Thermal protection with thermistors is advisable for applications prone to frequent load changes or environments with fluctuating temperatures. Thermistors monitor winding temperature, helping prevent overheating and allowing for safer, continuous operation.

Q: Where can these three phase motors be installed?

A: Our motors are suited for installation in industrial facilities, factories, process plants, and water supply systems-anywhere robust and reliable motor performance for pumps, compressors, machinery, or blowers is needed. Multiple mounting types allow flexible integration into new and existing systems.

Q: What is the process for ordering motors with custom specifications?

A: To order a motor with custom specifications, share your requirements such as power output, mounting type, voltage, efficiency class, color, and any optional features. Our team will review and provide tailored solutions based on application and technical standards.

Q: What makes these motors low maintenance and reliable?

A: Features like pre-lubricated ball bearings, robust housing, and sealed TEFC construction minimize wear and contamination. High efficiency and compliance with IS/IEC standards ensure dependable and low-maintenance operation over long service periods.

Q: How does using an IE2/IE3 efficiency class motor benefit my operations?

A: IE2 and IE3 efficiency classes indicate high energy performance, which translates to reduced power consumption and operational costs. Over time, this leads to significant savings and enhanced sustainability for industrial operations.
