B5 Three Phase Electric Motor

B5 Three Phase Electric Motor Specification

Starting Type
DOL (Direct On Line)

Features
Robust construction, Low maintenance, Energy efficient, Smooth Operation

Current Type
AC

Cooling Method
IC411 (self fan cooled)

Horse Power
1 HP - 400 HP

Rated Frequency
50/60 Hz

Rated Voltage
380V/415V/660V (standard)

Torque
High starting torque

Sealed Type
IP55 (Standard), IP56/IP65 (optional)

Pressure
Standard atmospheric/ambient

Motor Type
B5 Flange Mounted Three Phase Asynchronous Motor

Poles Number
2, 4, 6, 8 Poles

Efficacy
IE2/IE3

Ambient Temperature
-15C to 40C

Standard
IS 325, IEC 60034

Noise Level
<70 dB

Bearing Type
Double sealed ball bearing

Voltage
220/380 V or 380/660 V (as per model)

Power Rating
0.75 kW - 315 kW

Product Type
Three Phase Electric Motor

Output Power
0.75 kW - 315 kW (typical range for B5 motors)

Frequency (MHz)
50/60 Hz

Protect Feature
Totally Enclosed Fan Cooled (TEFC)

Phase
Three Phase

Speed
750-3600 RPM depending on pole configuration

Power
750 W - 315,000 W

Color
Blue

Dimension (L*W*H)
Varies by model (customizable as per requirement)

Weight
12 kg - 1800 kg

Shaft Diameter
Typically 24 mm - 100 mm (varies by power rating)

Mounting Type
Flange Mounted (B5)

IP Rating
IP55

Frame Material
Cast Iron/Aluminum

Insulation Class
F/H (Standard/Optional)

Rotor Type
Die-cast aluminum/copper squirrel cage

Cable Entry
Double cable gland entry

Duty Type
S1 (Continuous duty)

Ambient Humidity
<90% RH, non-condensing

Thermal Protection
PTC thermistor optional

Paint Coating
Anti-corrosive epoxy

About B5 Three Phase Electric Motor

With the Strong Passion for Providing a One-stop Solution to the Various Range of Industrial Solutions, We Emerged as a Successful Enterprise Today. We Excelled at Providing Premium Quality Ac Induction Motors. We Are Proud to Say That Our Electrical Motors Are Highly Recommended in All Industries.

Engineered for Long-Lasting Performance

Constructed with either cast iron or aluminum frames, the B5 Three Phase Electric Motor offers enhanced resilience against demanding industrial environments. Its anti-corrosive epoxy coating further safeguards the motor from harsh conditions, ensuring an extended lifespan and minimizing maintenance interruptions. High-quality bearings and robust construction allow for reliable operation in diverse applications.

Precision and Versatility in Every Application

With a wide output power range (0.75 kW to 315 kW) and multiple pole configurations, the motor is adaptable for various machinery requirements. Available in multiple voltage and frequency ratings, as well as flexible cable entry and mounting options, this motor is customizable to specific project needs. Both rotor and frame materials can be specified to suit operational demands.

Efficiency, Safety, and Compliance

The B5 Three Phase Electric Motor is engineered for optimal efficiency, meeting IE2 or IE3 standards for reduced energy consumption. Protection features include IP55 sealing (with higher ratings available) and optional PTC thermistor for enhanced thermal management. Complying with international standards (IS 325, IEC 60034), this motor prioritizes both safety and operational compliance.

FAQ's of B5 Three Phase Electric Motor:

Q: How should the B5 Three Phase Electric Motor be installed for optimal performance?

A: The B5 Three Phase Electric Motor is designed for B5 flange mounting and should be securely mounted on a compatible flat surface. Proper alignment with coupled equipment and strict adherence to wiring standards ensure smooth operation and longevity.

Q: What types of applications are suitable for this motor?

A: This motor is ideal for continuous duty (S1) industrial applications such as pumps, compressors, conveyors, fans, and various types of processing machinery due to its robust design, high starting torque, and smooth running capabilities.

Q: When is it recommended to use the optional PTC thermistor for thermal protection?

A: The optional PTC thermistor is advised for applications with frequent starts, heavy loads, or where continuous monitoring of motor temperature is required. It helps prevent overheating and extends the motor's service life.

Q: Where can I use the B5 Three Phase Electric Motor considering its IP rating?

A: With a standard IP55 rating (and IP56/IP65 optional), this motor is suitable for environments requiring protection from dust, splashes, and moderate water jets, such as factories, workshops, and outdoor sheltered installations.

Q: What is the process for selecting the correct power rating and pole configuration?

A: Determine your equipment's required torque, speed, and load characteristics. Then, select the appropriate power output (0.75 kW-315 kW) and pole number (2, 4, 6, or 8) to match the operational speed and torque profile for optimum efficiency.

Q: How does the motor's anti-corrosive epoxy paint benefit long-term usage?

A: The anti-corrosive epoxy coating provides effective protection against rust and chemical exposure, enhancing the motor's durability in harsh industrial and coastal environments while reducing the frequency of repainting or repairs.

Q: What advantages does the Totally Enclosed Fan Cooled (TEFC) feature provide?

A: TEFC design ensures that the motor components are protected from external contaminants such as dust, moisture, and debris. This promotes a longer operational life, safer usage, and lower maintenance compared to open-type motors.
